TrilinosWrappers::SparseMatrixIterators::Iterator< Constness > Class Template Reference

#include <deal.II/lac/trilinos_sparse_matrix.h>

Public Types
using	size_type = ::types::global_dof_index
using	difference_type = ::types::global_dof_index
using	value_type = TrilinosScalar
using	MatrixType = typename Accessor<Constness>::MatrixType

Public Member Functions
	Iterator (MatrixType *matrix, const size_type row, const size_type index)
template<bool Other>
	Iterator (const Iterator< Other > &other)
Iterator< Constness > &	operator++ ()
Iterator< Constness >	operator++ (int)
const Accessor< Constness > &	operator* () const
const Accessor< Constness > *	operator-> () const
template<bool OtherConstness>
bool	operator== (const Iterator< OtherConstness > &) const
template<bool OtherConstness>
bool	operator!= (const Iterator< OtherConstness > &) const
template<bool OtherConstness>
bool	operator< (const Iterator< OtherConstness > &) const
template<bool OtherConstness>
bool	operator> (const Iterator< OtherConstness > &) const

Static Public Member Functions
static ::ExceptionBase &	ExcInvalidIndexWithinRow (size_type arg1, size_type arg2)

Private Attributes
Accessor< Constness >	accessor

Friends
template<bool Other>
class	Iterator

Detailed Description

template<bool Constness>
class TrilinosWrappers::SparseMatrixIterators::Iterator< Constness >

This class acts as an iterator walking over the elements of Trilinos matrices. The implementation of this class is similar to the one for PETSc matrices.

Note that Trilinos stores the elements within each row in ascending order. This is opposed to the deal.II sparse matrix style where the diagonal element (if it exists) is stored before all other values, and the PETSc sparse matrices, where one can't guarantee a certain order of the elements.

Definition at line 351 of file trilinos_sparse_matrix.h.

Member Typedef Documentation

size_type

template<bool Constness>

using TrilinosWrappers::SparseMatrixIterators::Iterator< Constness >::size_type = ::types::global_dof_index

Declare type for container size.

Definition at line 357 of file trilinos_sparse_matrix.h.

difference_type

template<bool Constness>

using TrilinosWrappers::SparseMatrixIterators::Iterator< Constness >::difference_type = ::types::global_dof_index

A type that denotes what data types is used to express the difference between two iterators.

Definition at line 363 of file trilinos_sparse_matrix.h.

value_type

template<bool Constness>

using TrilinosWrappers::SparseMatrixIterators::Iterator< Constness >::value_type = TrilinosScalar

An alias for the type you get when you dereference an iterator of the current kind.

Definition at line 369 of file trilinos_sparse_matrix.h.

MatrixType

template<bool Constness>

using TrilinosWrappers::SparseMatrixIterators::Iterator< Constness >::MatrixType = typename Accessor<Constness>::MatrixType

Typedef for the matrix type (including constness) we are to operate on.

Definition at line 375 of file trilinos_sparse_matrix.h.

Constructor & Destructor Documentation

Iterator() [1/2]

template<bool Constness>

TrilinosWrappers::SparseMatrixIterators::Iterator< Constness >::Iterator	(	MatrixType *	matrix,
		const size_type	row,
		const size_type	index )

Constructor. Create an iterator into the matrix matrix for the given row and the index within it.

Iterator() [2/2]

template<bool Constness>

template<bool Other>

TrilinosWrappers::SparseMatrixIterators::Iterator< Constness >::Iterator

(

const Iterator< Other > &

other

)

Copy constructor with optional change of constness.

Member Function Documentation

operator++() [1/2]

template<bool Constness>

Iterator< Constness > & TrilinosWrappers::SparseMatrixIterators::Iterator< Constness >::operator++

(

)

Prefix increment.

operator++() [2/2]

template<bool Constness>

Iterator< Constness > TrilinosWrappers::SparseMatrixIterators::Iterator< Constness >::operator++

(

int

)

Postfix increment.

operator*()

template<bool Constness>

const Accessor< Constness > & TrilinosWrappers::SparseMatrixIterators::Iterator< Constness >::operator*

(

)

const

Dereferencing operator.

operator->()

template<bool Constness>

const Accessor< Constness > * TrilinosWrappers::SparseMatrixIterators::Iterator< Constness >::operator->

(

)

const

Dereferencing operator.

operator==()

template<bool Constness>

template<bool OtherConstness>

bool TrilinosWrappers::SparseMatrixIterators::Iterator< Constness >::operator==

(

const Iterator< OtherConstness > &

)

const

Comparison. True, if both iterators point to the same matrix position.

operator!=()

template<bool Constness>

template<bool OtherConstness>

bool TrilinosWrappers::SparseMatrixIterators::Iterator< Constness >::operator!=

(

const Iterator< OtherConstness > &

)

const

Inverse of ==.

operator<()

template<bool Constness>

template<bool OtherConstness>

bool TrilinosWrappers::SparseMatrixIterators::Iterator< Constness >::operator<

(

const Iterator< OtherConstness > &

)

const

Comparison operator. Result is true if either the first row number is smaller or if the row numbers are equal and the first index is smaller.

operator>()

template<bool Constness>

template<bool OtherConstness>

bool TrilinosWrappers::SparseMatrixIterators::Iterator< Constness >::operator>

(

const Iterator< OtherConstness > &

)

const

Comparison operator. The opposite of the previous operator

Friends And Related Symbol Documentation

Iterator

template<bool Constness>

template<bool Other>

friend class Iterator

friend

Definition at line 460 of file trilinos_sparse_matrix.h.

Member Data Documentation

accessor

template<bool Constness>

Accessor<Constness> TrilinosWrappers::SparseMatrixIterators::Iterator< Constness >::accessor

private

Store an object of the accessor class.

Definition at line 457 of file trilinos_sparse_matrix.h.

---

The documentation for this class was generated from the following file:

• include/deal.II/lac/trilinos_sparse_matrix.h
